Aquarius II 26M Dive Cat

'Aquarius II' 26M Tour/Dive Catamaran

We are thrilled to introduce the latest design, Aquarius II. This bespoke 26 metre aluminium dive catamaran is the perfect vessel for operations based out to the Great Barrier Reef, Australia.

Aquarius II has exceeded all expectations, exceeding a high cruising speed at low RPM, running trim was perfect and the hull gave off a relatively low wash. It is powered by twin MTU 8V 2000 (965hp) diesel marine engines and conventional prop/shaft with a top speed of over 30 knots, with a cruising speed of 27 knots and operating speed of 25 knots cruise at 70% load, with amazing fuel burn. Click here for Video

With a semi-displacement deep vee type hull and plumb bow design, the waterline length has been maximized and maintains the measured length of under 24 meters LOA. Not only is the vessel fuel efficient, but it also has an extended range capability for delivery voyages or extended cruising time.

Designed to cater to daily dive charters, Aquarius II is equipped with the latest technology including an inbuilt air compressor and hydraulic (two-stage) dive platform for snorkeling and scuba diving. The aft’ dive deck has four toilets including hot and cold water showers as well as wet suit lockers. Additionally, this vessel is spacious and comfortable, featuring forward walk-around sides on the upper deck with large forward and aft’ lounge decks making it one of the most popular vessels in its class.

Designed in accordance with the NSCV (AMSA) Class 1C, Aquarius II is licensed to carry 125 divers plus 5 crew in coastal waters, however, it can also be utilized as a ferry to carry over 200 passengers. With its versatile design, this vessel is also suited for overnight accommodation versions with typically six spacious guest cabins plus two crew cabins. The structure is to Lloyds Register SSC standard for offshore operations, ensuring that Aquarius II meets all the required safety standards. Click here for video

SPECIFICATIONS

Name of Vessel: "Aquarius II" Type of Vessel: Dive/Tourist Catamaran

In Survey to: NSCV 1C Home Port: Port Douglas, Australia

Owner: Tour Co Designer: Sea Speed Designs

CAD Software: MAXSURF Builder: Sea Cat Ships Thailand

Hull Construction ALUMINIUM Superstructure ALUMINIUM

Deck Construction ALUMINIUM Length Overall: 25.96M

Length Waterline: 24.82M Length bp.: 23.97M

Beam: 9 .00M Draught: 1.75M

Depth: 2.36M Displacement: 75 TONNE

Tonnage/s: 155 GRT Main Engine/s: 2 X MTU 8 V 2000 M72

Power 2 x 965HP @ 2250RPM Gearbox/s: ZF 665A

Propulsion: Prop/Shaft Maximum Speed: 30 KNOTS

Cruising Speed: 27 KNOTS Generator/s: Zenith 60 KVA

Side Thruster/s: NIL Steering System: UMP Electric Hydraulic

Hydraulic Equipment: UMP Electronics Supplied By: UMP

Electronics Installed Palm Electrics Depth Sounder/s: Simrad

Radio/s: ICOM Autopilot: NAC-2

Compass/es: Ritchie AIS: NA15-500 Class 1B

GPS: Simrad Radar: Simrad NSO EV0 35

Sound System: Fusion Video System: Wirless

Other Electronics: CCTV & DVR Electrical By: Bensen & Brown

Electrics installed by: Palm Electrical Capstan/Windlass: Muir VR4500

Tank Gouges: ITIM Deck Equipment: Dive Platform

Other Equipment Installed: Dive Compressor Alarm System/s: Systems Advantage (Sea Fire)

Paints/Coatings: Jotun Windows: Aus Marine Windows

Seating: In House/Seaborn Flooring/Deck Surface Finishes: Non-Skid Paint

Interior Fit out: Painted Aluminium Anchors: 1 X Manson SUP 225

Liferaft/s: 2 x 65Man RFD Tender Boat/s: Highfield Classic 380

Sullage Capacity: 1 x 1000 LTR Fuel Capacity: 9000LTR

Fuel Consumption: 300 ltr/hr @ 25 KN, 46 ltr/hr @ 10 KN

Freshwater Capacity: 1 x 1000 LTR Crew: 5

Passengers: 125 Pax Range: 2500 NM @ 10Knots

Vehicles: - Type of operation Envisaged: Charter, Dive

Operational Area: Coastal Date of Delivery: 1nd Quarter 2023
